M5 4pin Male Panel Mount,Solder contacts
M5 4pin Male Panel Mount,Solder contacts
Publish:SHENZHEN CP-LINK ELECTRONIC CO.,LTD  Time:2014-01-19

  • Degree of protectioin IP67

    3, 4 poles are available

  • RoHS & REACH Compliance


  • Electrical Data
  • Rated voltage:
  • 60V
  • Insulation resistance:
  • ≥100MΩ
  • Rated current:
  • 1A
  • Contact resistance:
  • ≤5mΩ
  • Ambient temperature:
  • -25℃~+80℃

  • Connector Specification
  • Polarity:
  • 3pins, 4pins
  • Contacts:
  • Brass with gold plated
  • Insert:
  • TPU
  • Coupling nut/screw:
  • Brass with nickel plated
  • Degree of protection:
  • IP67 in locked condition

  • Cable/Wire Specification
  • Core insulation material:
  • PVC
  • Core insulation colours:
  • Customized solution
  • Core cross-section:
  • 26AWG or 0.14mm2
