SHENZHEN CP-LINK ELECTRONIC CO.,LTD
| Connector locking system | Screw-locking |
| Termination | crimp, overmoulded on cable |
| Wire gauge (mm) | 0,25 mm² or 0.34mm² |
| Wire gauge (AWG) | 22~24 |
| Cable lenth | optional |
| Degree of protection | IP68 |
| Mechanical operation | >100 mating cycles |
| Upper temperature | +85 °C or +105 °C |
| Lower temperature | -25 °C or -40 °C |
| Rated voltage | 250V, 10~30V with led |
| Rated impulse voltage | 2500V, 500V with led |
| Rated current (40°C) | 4A |
| Volume resistivity | ≤ 3 mΩ |
| Contact plating | Au (gold) |
| Material of contact body | PUR |
